Headsets

- Fork crown race for genuine Ritchey headsets - Alloy with 45-degree taper

- Steel cups - Steel retainer bearings - Available in chrome or black - Steerer Dia: 25.4mm - Cup Dia: 30mm

- Steel cups - Steel retainer bearings - Available in chrome or black - S.H.I.S.: EC32/25.4-24tpi|EC32/27 - Steerer Dia: 25.4mm - Cup Dia: 32.5mm

Crown races for Wolf Tooth headsets. - For Wolf Tooth headsets

Crown races for Cane Creek headsets fit a variety of lowers and crown race seat diameters. - Compatible with 10-, 40- and 110-Series headsets and backwards compatible with S and XX Series - Integral mold seals keep out the elements - Durable steel construction

Custom Cane Creek lower race for Salsa.

- Forged steel cups with caged 5/32" ball bearings - TH-857 features a alloy top cover - TH Series: External Cup, traditional - S.H.I.S.: EC34/28.6|EC34/30 - Stack: 14.9mm/11mm - Color: Black - Weight: 126g

• Steel • Retainer ball bearings, includes top cap and star nut • 1 1/8 inch • S.H.I.S.: EC34/28.6, EC34/30

• Steel • Retainer ball bearings, includes top cap and star nut • 1 inch • S.H.I.S.: EC30/25.4, EC30/26

Compression plug for Wolf Tooth headsets. - Compression plug works with steerer tube inner diameters ranging from 23.2mm to 24.2mm

Lightweight aluminum alloy - Non-Keyed - Height: 20mm - 10 to a bag

- Steel cups - Steel retainer bearings - Available in chrome or black - S.H.I.S.: EC34/28.6-26tpi|EC34/30 - Steerer Dia: 28.6mm - Cup Dia: 34mm - Race Dia: 30mm - Stack Ht: 40mm Size: 1-1/8"

The Ritchey Logic Threadless headset features a smaller upper bearing to save weight, while the oversize lower bearing is designed to handle loads. Deep bearing cups promise solid insertion. - Bearing: Retainer ball bearing - Material: Steel/Plastic - Stack Height: 28.3mm

- No. series headsets offer excellent performance and value - No. 8b: 36x45 degree Cane Creek Integrated, or No. 10: Zero Stack shallow available for 1-1/8" applications - No. 10 S.H.I.S.: ZS44/28.6|ZS44/30 - No. 8B S.H.I.S.: IS42/28.6|IS42/30 - Stack: 5.2mm/3.7mm (No. 10), 8mm/1mm (No. 8B) - Color: Black - Weight: 93g (No. 10), 74g (No. 8B)

Replacement headset uppers from FSA. - S.H.I.S. Stem Clamp Diameter: 28.6 Threadless - Bearing Type: Cartridge - S.H.I.S Upper: IS41 - Upper Stack Height: 8.2

- CrMo headset with oversized 3/16" lower ball bearings, 5/32" upper bearings and a nylon top cover - Hammer: External Cup, traditional - S.H.I.S.: EC34/28.6|EC34/30 - Stack: 12.8mm/11.9mm - Color: Black - Weight: 149g

- CrMo headset with oversized 3/16" lower ball bearings, 5/32" upper bearings and an alloy top cover - Mallet: External Cup, traditional - S.H.I.S.: EC34/28.6|EC34/30 - Stack: 15.4mm/13.6mm - Color: Black - Weight: 150g

- Carbon fiber top caps, bolt and steel star nut - Size: 1-1/8" - Color: Black - Weight: 21g

The Sunday BMX headset is a quality headset at an affordable price: period. It offers one of the lower stack heights on the market and uses a Campagnolo standard spec for 1-1/8-inch integrated headsets. - 45º tapered bearings with 41.8mm outer diameter to fit 42mm BMX head tubes - Compatible with Odyssey GTX Gyro, GTX-R, GTX-S and Snafu Mobeus. - Comes with matching 3mm and 5mm spacers - Weight with/without spacers: 2.1/2.3 oz.

- Steel cup semi-integrated design - Threaded semi-integrated design - Fits many Sun cruisers and others - Caged bearing 5/32" x 22A - Cup Diameter: 44mm - Race Diameter: 30mm - Stack Height: 18.2mm

- 3-piece expander design provides a secure fit within carbon steerer tubes - 22-25mm range of expansion - 50mm height reinforces carbon steerer tube beneath the stem - New design evenly distributes headset compression forces - Lightweight AL6061 alloy construction - Stainless steel bolt

- 3-piece expander design provides a secure fit within carbon steerer tubes - 22-25mm range of expansion - 50mm height reinforces carbon steerer tube beneath the stem - New design evenly distributes headset compression forces - Lightweight AL6061 alloy construction - Stainless steel bolt

A new headset gives you a new lease on life. This is the upper part of an integrated headset for a 44mm headtube. - Lower part of the headset sold separately

- Pig DH-Pro feature angular contact sealed upper bearing and an industrial cartridge sealed bearing with an alloy upper cup and CrMo lower cup - Pig feature oversized 1/4" lower ball bearings, 5/32" upper bearings - Big Fat Pig feature super oversized caged ball bearings - Pig: External Cup, traditional - Pig S.H.I.S.: EC34/28.6|EC34/30 - Big Fat Pig S.H.I.S.: EC49/38.1|EC49/40 - Pig DH Pro S.H.I.S.: EC34/28.6|EC34/30 - Stack: 15.4mm/13.6mm (Pig), 17mm/11.7mm (Big Fat Pig), 15.5mm/16mm (Pig DH Pro) - Color: Black - Weight: 193g (Pig), 345g (Big Fat Pig), 198g (Pgi DH Pro)

The Revolver headset features a high precision CNC 6061 Aluminum bearing cover with triple rubber seals for a perfect fit. - Campy spec 45x45 sealed bearings - 15mm dust cover stack height - 2.7oz (76.54g) - Materials: Aluminum Cover, Chromoly Crown Race

Cane Creek's Aheadset is a simple, affordable solution for your headset needs. • Bearing Type: Cup and Cone • Color: Black • Crown Race: 26 • Defined Color: Black • Lower Stack Height: 12 mm • S.H.I.S Lower: EC30 • S.H.I.S Upper: EC30 • S.H.I.S. Stem Clamp Diameter: 25.4-24tpi Quill • Upper Stack Height: 22 mm • Weight: 205 g

For bikes featuring integrated headsets (such as the Ritchey Road Logic and Swiss Cross), the Comp Drop In Integrated Headset stands above all others. The Comp features full-complement stainless steel angular contact cartridge bearings packed with Ritchey high-webbing grease. - Top cap: 8.3 or 15.3mm - Material: Alloy - Upper Fit (S.H.I.S.): IS42/28.6 - Lower Fit (S.H.I.S.): IS42/30 - Upper Bearing OD: 41.8 - Lower Bearing OD: 46/42 - Top Cover OD: 46 - Bearings: Sealed cartridge - Weight: 74g

Cane Creek's 10 Series has light, tough, and beautiful machined 6061 T6-aluminum cups, Cane Creek's corrosion-resistant black-oxide angular-contact bearings and quality seals throughout to keep the grease in and the dirt out. • Technical Description: ZS44/28.6/H8/K|ZS44/30/H4/K • Top Type: ZS - ZeroStack • Top Head Tube Inside Dia.: 44.00mm • Stem Clamp Dia.: 28.6mm • Top Stack Height: 8mm (Short), 15mm (Tall) • Top Bearing Type: Black Oxide • Material: 6061 aluminum • Weight: 62.79g

Cane Creek's 10 Series has light, tough, and beautiful machined 6061 T6-aluminum cups, Cane Creek's corrosion-resistant black-oxide angular-contact bearings and quality seals throughout to keep the grease in and the dirt out. • Technical Description: ZS56/40/H4/K • Bottom Type: ZS - ZeroStack • Bottom Head Tube Inside Dia.: 55.95mm • Crown Race Seat Dia.: 39.79mm • Crown Race Type: Polymer • Bottom Stack Height: 4mm • Bottom Bearing Type: Black Oxide • Material: 6061 aluminum • Weight: 35.35g

- Weight: 160g - Crown Race: 30 - S.H.I.S. Lower: EC34 - S.H.I.S. Upper: EC34 - S.H.I.S. Stem Clamp Diameter: 28.6 Threadless
